152*24 316L Stainless Steel Wire Mesh Roll / Plain Dutch Weave Mesh 1M Width

Ask Lasest Price
Brand Name :	Sour Wire Mesh
Certification :	ISO9001
Price :	$65/ROLL
Payment Terms :	L/C, T/T
Supply Ability :	50ROLLS/DAY
Model Number :	152x24
Delivery Time :	15days

Add to Cart

Product Details
Company Profile

152*24 316L Stainless Steel Wire Mesh Roll / Plain Dutch Weave Mesh 1M Width

152x24 mesh plain reverse dutch weave stainless steel wire mesh filter cloth for plastic extruder

prodcuct description:

Reverse Dutch weave wire cloth is woven using two sizes of wire. Smaller wires are used in the warp direction and are woven with a larger shute wire. The smaller wires are woven tightly together, providing a tight mesh for filtering. The larger wire provides strength to the mesh. The primary uses of this wire cloth are filtration and separation of liquid and slurry products.

Reverse Twill Dutch weave wire cloth combines Dutch and twill weaving to provide a fine mesh filtering cloth. The weaving process allows for the use of very fine wires, producing filtering mesh for gas and liquid applications. We also provide Herringbone and Broken Pattern Reverse Twill Dutch Weave Products.

Name	Automatic continuous screen changer using mesh belt filter
Weave types	Reverse Plain Dutch Weave and Reverse Twill Dutch Weave
Materials	304,304L,316,316L 904 904L 310 310s 410 430 etc.
Feature	High Tensile Warp wire for Auto-Screen changers used in the Plastic Extrusion Industry. Rubbed Edges after slitting to help with tracking for Auto-Screen changers. Plasma and laser cut parts to help prevent edges wire fraying. 100% Inspection of Wire Cloth for critical applications such as sand screens and aerospace applications.
Application	Suitable for plastic wire drawing machine, stretch film machine, coating machine filters, such as plastic woven bag, plastic film. Used for plastic recycling filter, otherwise wafer type, square type, single or multi-layer molding machine filter.
Standard Specs	48x10 mesh RDPW 400 nominal micron 72x15 mesh RDTW 250 nominal micron 132x16 mesh RDTW 200 nominal micron 152x30 mesh RDTW 115 nominal micron 250x40 mesh RDTW 75 nominal micron
Width of belt	10cm 12cm 15cm 19cm 21cm all available, sample free for check quality !!

Technology :

152*24 316L Stainless Steel Wire Mesh Roll / Plain Dutch Weave Mesh 1M Width
