    12X64 mesh 304 Stainless Steel Wire Mesh Screen Plain Dutch Weave 3m Width

    Ask Lasest Price
    Brand Name : Source Wire Mesh
    Model Number : 12x64mesh
    Certification : ISO9001
    Price : Negotiable
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 20Rolls/Week
    Delivery Time : 5 days
    • Product Details
    • Company Profile

    12X64 mesh 304 Stainless Steel Wire Mesh Screen Plain Dutch Weave 3m Width

    Plain dutch weave 12X64mesh 304/316/316L stainless steel woven wire mesh


    Plain dutch weave 12X64mesh 304/316/316L stainless steel woven wire mesh product description:


    Dutch weave filter mesh provides superior filtration capabilities for a wide range of applications, including pressure, fuel and liquid filters for the aerospace, petrochemical, pharmaceutical, mining and waste water treatment industries.

    1. Material: 304 316 316L stainless steel wire mesh

    2. Mesh count: 12x64, 20x300, 30x150, 40x200, 40x250, 80x400, 80x600, 200x14mm, 325x2300 etc

    3. Roll width: 3', 1.0m, 1.2m etc

    Customized outside diameter

    4. MOQ: 3m2

    5. Delivery time: within 5 days


    Plain dutch weave wire mesh specifications
    Item
    Mesh
    Wire diameter(Warp x Weft)
    Hole size/Micron
    KGS/M2
    32#
    8 x 62
    0.63mm x 0.45mm
    300
    5.42
    40#
    10 x 79
    0.50mm x 0.355mm
    250
    3.16
    48#
    12 x 64
    0.58mm x 0.40mm
    280
    2.9
    76#
    19 x 140
    0.315mm x 0.20mm
    140
    1.88
    80#
    20 x 300
    0.35mm x 0.20mm
    -
    3.6
    95#
    24 x 110
    0.355mm x 0.25mm
    120
    2.45
    100#
    25 x 140
    0.28mm x 0.20mm
    100
    1.95
    120#
    30 x 150
    0.25mm x 0.18mm
    80
    1.68
    160#
    40 x 200
    0.20mm x 0.14mm
    60
    1.40
    180#
    45 x 250
    0.16mm x 0.112mm
    56
    1.09
    200#
    50 x 250
    0.14mm x 0.11mm
    53
    1.04
    240#
    65 x 330
    0.11mm x 0.08mm
    36
    0.71
    280#(1)
    70 x 350
    0.11mm x 0.08mm
    35
    0.72
    280#(2)
    70 x 385
    0.11mm x 0.07mm
    32
    0.75
    300#
    78 x 700
    0.11mm x 0.08mm
    30
    1.39
    315#(1)
    80 x 400
    0.10mm x 0.065mm
    40
    0.62
    315#(2)
    80 x 600
    0.10mm x 0.06mm
    -
    -
    315#(3)
    80 x 800
    0.15mm x 0.04mm
    -
    -
    320#
    81 x 780
    0.10mm x 0.07mm
    30
    1.22
    354#
    90 x 550
    0.12mm x 0.05
    -
    -
